| MODEL | CTE | |
| Full stroke ranges | 0.5, 1, 2m | |
| Output signal | voltage divider (encoder) | |
| Accuracy | ±0.05% F.S | |
| Repeatability | ±0.02% F.S | |
| Measuring cable | φ0.45 stainless steel | |
| Power supply | 5V,12V,24V,DC+5~+24V(Ripple:P-P Max 5%) | |
| Current consumption | less than 80mA(at no load condition) | |
| less than 150mA(line driver output at no load condition) | ||
| Operation temperature | -10℃ ~ +70℃(line driver 0℃~70℃) | |
| Operating humidity | 35 ~ 85% RH | |
| Cable | 4P(AWG26) Shield cable | |
